PROFIBUS Line in Drawout Systems where PDP32.0 is installed on UMC100.3


LT
LT
Repeater
Last node in line: PROFIBUS termination
unit PDR31 mounted on single mounting
kit SMK3.0. 24VDC supplied
Optional connection of configura-
tion adapter
Configuration adapter UTP22
Service laptop
PROFIBUS
Master
Termination active
UMC100.3 with PROFIBUS
communication interface
PDP32 mounted in drawer
9 UNIVERSAL MOTOR CONTROLLER UMC100.3
