ABB PSE18 - Page 177

Softstarters Type PSE18...PSE370 User Manual short form 1SFC132059M9901 177
PSE210-600-70
550 mm (21.653 in)
532 mm (20.944 in)
9,2 mm (0.363 in)
6,5 mm (0.256 in)
163,5 mm (6.437 in)
125,5 mm (4.941 in)
236,5 mm (9.311 in)
5 mm (0.197 in)
190 mm (7.480 in)
19,6 mm
(0.772 in)
470 mm (18.503 in)
40 mm (1.575 in)
1SFC132266F0001
43,75 mm
(1.723 in)
PSE210...PSE370
