Softstarters Type PSE18...PSE370 User Manual short form 1SFC132059M9901 5
EN
The PSE Softstarter is microprocessor-based and designed with the
latest technology for soft starting, and when applicable, soft stopping of
standard squirrel cage motors.
The PSE Softstarter has several features as standard.
Integrated by-pass.
Torque control ramp during start and stop.
Built in Electronic Motor protection.
Analog out signal can vary in the range 4 - 20 mA, corresponding
to 0 - 120 percent of set I
e
(terminals 12 and 13). 100 percent cor-
responds to 17.3 mA.
Three output signal relays to indicate Top of Ramp (TOR), trip
events (FAULT) and running (RUN).
The PSE Softstarter can be controlled in two ways:
Hardwire inputs using terminals 8 and 9, in circuit with terminals 11
or 12.
Fieldbus communication interface.
1. Check that you have the correct product in regards to operational volt-
age, control supply voltage, rated motor data, and used numbers of
starts per hour.
The PSE18...PSE370 Softstarters operates over wide voltage ranges.
Rated operational voltage 208 - 600 V AC
Rated control supply voltage 100 - 250 V AC
of the ambient temperature and altitude above sea level. Derating is
required above 40 °C (104 °F) and above 1000 m (3281 ft). For more
details see Softstarters Type PSE18...PSE370, Installation and Com-
missioning Manual, Document ID 1SFC132057M0201 available on:
http://www.abb.com/lowvoltage.
2. Make sure that any of the recommended short circuit protections are
used according to prevailing standards.
2 Description
