Softstarters Type PSE18...PSE370 User Manual short form 1SFC132059M9901 9
EN
13
7. Switch ON the control supply voltage, terminals 1 and 2.
8. Continue to congure parameters as described in chapter 6, Settings.
9. Switch ON the operational voltage.
-
lowing the steps above will enable operation of the PSE softstarter. An
example of a complete installation can be found in the graphics section.
circuit breaker.
Depending on the two phase control, a connected motor terminal
always carries live hazardous voltage. Do not touch terminals when
voltage is applied. Output terminals will have live voltage even when the
device is OFF. This can cause death or serious injury.
