100 Functions | Installation and commissioning manual | 1SFC132081M0201
Parameter Description Setting range Default value
12.22 Fieldbus AI 1 Sets the AI 1 programmable
analog input signal.
None,
Phase L1 current1,
Phase L2 current1,
Phase L3 current1,
Active power (HP),
Active power,
Apparent power,
Mains voltage,
Power factor,
Motor voltage,
Active energy (resettable),
EOL time to trip,
Mains frequency,
Max phase current,
Motor current,
Motor run time (resettable),
Motor temperature,
Motor temperature percent,
Number of starts (resettable),
Phase sequence,
PT100 temperature,
PTC resistance,
Reactive energy (resettable),
Reactive power,
Remaining time to start,
Thyristor temperature,
Thyristor temperature percent,
EOL time to cool,
Top event code,
Motor current in percent of IE.,
Thyristor run time (resettable)
Phase L1 current
12.23 Fieldbus AI 2
Sets the AI 2 programmable
analog input signal.
Phase L2 current
12.24 Fieldbus AI 3
Sets the AI 3 programmable
analog input signal.
Phase L3 current
12.25 Fieldbus AI 4
Sets the AI 4 programmable
analog input signal.
Max phase current
12.26 Fieldbus AI 5
Sets the AI 5 programmable
analog input signal.
Mains frequency
12.27 Fieldbus AI 6
Sets the AI 6 programmable
analog input signal.
Motor voltage
12.28 Fieldbus AI 7
Sets the AI 7 programmable
analog input signal.
Motor temperature
percent
12.29 Fieldbus AI 8
Sets the AI 8 programmable
analog input signal.
Number of starts
(resettable)
12.30 Fieldbus AI 9
Sets the AI 9 programmable
analog input signal.
Motor run time
(resettable)
12.31 Fieldbus AI 10
Sets the AI 10 programmable
analog input signal.
Top event code
* Restrictions on which baud rates you can use for
different protocols.
Baudrate Modbus RTU on Com 3 Modbus RTU Anybus Devicenet on Anybus
1200 x
2400 x
4800 x
9600 xx
19200 xx
38400 x
57600 x
76800 x
115200 x
125000 x
250000 x
500000 x
Auto baud x
