1SFC132081M0201 | Installation and commissioning manual | Functions 99
Parameter Description Setting range Default value
12.12 Fieldbus DI 1 Sets the DI 1 programmable
digital input signal.
None,
Startfeedback,
Stopfeedback,
Faultresetfeedback,
Slowspeedrevfeedback,
Slowspeedforw2566feedback,
Start1feedback,
Start2feedback,
Start3feedback,
Motorheatingfeedback,
Userdefinedfeedback,
Standstillbrakefeedback,
Emergencymodefeedback,
Startreversefeedback,
Runstatus,
TORstatus,
Line,
Phasesequence,
Eventgroup0status,
Event group 1 status,
Event group 2 status,
Event group 3 status,
Event group 4 status,
Event group 5 status,
Event group 6 status,
Sequence 1 Run status,
Sequence 2 Run status,
Sequence 3 Run status,
Sequence 1 TOR status,
Sequence 2 TOR status,
Sequence 3 TOR status,
Run reverse status,
Enablestatus,
DigitalIn0status,
DigitalIn1status,
DigitalIn2status,
Localcontrolstatus,
Cancel brake feedback,
Pump cleaning auto status,
Pump cleaning forward status,
Pump cleaning backward status,
External digital 1DI0 status,
External digital 1DI1 status,
External digital 1DI2 status,
External digital 1DI3 status,
External digital 1DI4 status,
External digital 2DI5 status,
External digital 2DI6 status,
External digital 2DI7 status
Line
12.13 Fieldbus DI 2 Sets the DI 2 programmable
digital input signal.
Phase sequence
12.14 Fieldbus DI 3 Sets the DI 3 programmable
digital input signal.
Event group 0 status
12.15 Fieldbus DI 4 Sets the DI 4 programmable
digital input signal.
Event group 1 status
12.16 Fieldbus DI 5 Sets the DI 5 programmable
digital input signal.
Start feedback
12.17 Fieldbus DI 6 Sets the DI 6 programmable
digital input signal.
Stop feedback
12.18 Fieldbus DI 7 Sets the DI 7 programmable
digital input signal.
Eventgroup 2 status
12.19 Fieldbus DI 8 Sets the DI 8 programmable
digital input signal.
Eventgroup 3 status
12.20 Fieldbus DI 9 Sets the DI 9 programmable
digital input signal.
Eventgroup 4 status
12.21 Fieldbus DI 10 Sets the DI 9 programmable
digital input signal.
Eventgroup 5 status
