98 Functions | Installation and commissioning manual | 1SFC132081M0201
Fieldbus Inputs/Outputs
Functions set in the Softstarter as Fieldbus digital inputs
(DI) are in fact the digital inputs to the PLC i.e. the data
flow from the Softstarter through the network to the PLC.
Fieldbus digital outputs (DO) are not configurable. The
output (DO) gives a description of data flow from the
network to the Softstarter i.e. appears as an input, from
the Softstarter point of view.
Fieldbus communication has these parameters:
Parameter Description Setting range Default value
12.01 Com3 function Sets the function of the Com3
port.
None, Test, Modbus RTU slave,
Extension IO
Test
12.02 FB interface connector Sets the Fieldbus interface
selection.
FbPlug, Modbus RTU, Anybus,
None
None
12.03 Fieldbus control Enables control from fieldbus. Off, On Off
12.04 Fieldbus address Sets the Bus address. 0 ... 65535 0
12.05 Fieldbus ip address Fieldbus IP: Sets the IP-
address.
0.0.0.0 ... 255.255.255.255 0.0.0.0
12.06 Fieldbus ip gateway Fieldbus IP: Sets the default
gateway.
0.0.0.0 ... 255.255.255.255 0.0.0.0
12.07 Fieldbus ip netmask Fieldbus IP: Sets the netmask. 0.0.0.0 ... 255.255.255.255 255.255.255.0
12.08 Fieldbus ip dhcp client Fieldbus IP: Enables dhcp. Off, On Off
12.09 FB baud rate* Sets the baud rate of internal
modbus-RTU interface,
Anybus DeviceNet and Anybus
modbus-RTU.
1200, 2400, 4800, 9600, 19200,
38400, 57600, 76800, 115200,
125000, 250000,500000, Auto
* There are restrictions
on which baud rates
you can use for
different protocols. See
separate Table below.
12.10 FB parity Sets parity for Anybus modbus-
RTU.
No parity, Odd parity, Even parity Even parity
12.11 FB stop bits Select stop bits for Anybus
modbus-RTU.
1 Stop bit, 2 Stop bits
1 Stop bit
