1SFC132081M0201 | Installation and commissioning manual | Functions 133
7.25 Complete parameter list
Parameter
number
Description Setting range Number of
decimals
Fieldbus
ID
Default value Actual
setting
01 Motor rated current Ie
01.01 Motor rated current Ie 9.0 ... 1250.0 A 1 1 30 A
02 Start and stop
02.01 Start mode Voltage ramp, Torque ramp, Full voltage start 0 2 Voltage ramp
02.02 Stop mode No ramp, Voltage ramp, Torque ramp 0 3 No ramp
02.03 Start ramp initial level 10 ... 99% 0 4 30%
02.04 Start ramp time 1 ... 120 s 0 5 10 s
02.05 Stop ramp end level 10 ... 99% 0 6 30%
02.06 Stop ramp time 1 ... 120 s 0 7 10 s
02.07 Pre-start function Pre start off, Motor heating, Stand still brake
Slow speed forward, Slow speed reverse
0 93 Pre start off
02.08 Pre-start time 0.0 ... 7200.0 s 1 128 10.0 s
03 Limit
03.01 Current limit type Off, Normal, Dual, Ramp 0 18 Off
03.02 Current limit level 1.5 ... 7.5 x I
e
1 19 4.0 x I
e
03.03 2nd curr lim level 0.5 ... 7.5 x I
e
1 20 7.0 x I
e
03.04 2nd curr lim time 2 ... 120 s 0 21 8 s
03.05 Torque limit level 20 ... 200% 0 170 150%
04 Kick start
04.01 Kick start On / Off 0 22 Off
04.02 Kick start level 50 ... 100% 0 23 70%
04.03 Kick start time 0.2 ... 2.0 s 2 24 0.20 s
05 Slow speed
05.01 Slow speed forward Fast jog, Jog, Creep 0 184 Jog
05.02 Slow speed fwd strength 10 ... 100% 0 187 50%
05.03 Slow speed reverse Fast jog, Jog, Creep 0 188 Jog
05.04 Slow speed rev strength 10 ... 100% 0 189 50%
06 Motor heating
06.01 Motor heating capacity 10 ... 100000 W 0 304 10 W
06.02 Motor heating temperature 10 ... 100000 W 10 W
06.03 Motor heating type Off, Manual 0 Off
07 Motor braking
07.01 Stand still brake strength 10 ... 100 0 305 50%
07.02 Motor brake time 1.0 ... 100.0 s 1 1.0 s
07.03 Dynamic brake strength 10 ... 100 % 0 40 %
07.04 DC brake strength 10 ... 100 % 0 40 %
07.05 DC brake switch speed
threshold
10 ... 100 % 0 28 %
07.06 DC brake switch delay time 0.1 ... 100.0 s 1 3.0 s
08 Sequence start
08.01 Sequence mode On / Off 0 8 Off
08.02 Ie seq 1 9.0 ... 1250.0 A 1 190 30 A
08.03 Start mode seq 1 Voltage ramp, Torque ramp, Full voltage start 0 191 Voltage ramp
08.04 Start ramp time seq 1 1 ... 120 s 0 192 10 s
08.05 Start ramp init lvl seq 1 10 ... 99% 0 193 30%
08.06 Curr lim level seq 1 0.5 ... 7.5 x I
e
1 194 7.0 x I
e
08.07 Kick start seq 1 On / Off 0 195 Off
08.08 Kick start level seq 1 50 ... 100% 0 196 70%
08.09 Kick start time seq 1 0.20 ... 2.0 s 2 197 0.20 s
08.10 Torque lim lvl seq 1 20 ... 200% 0 198 150%
08.11 Torque tune seq 1 0 ... 1000% 0 199 100%
08.12 Torque ctrl gain seq 1 0.01 ... 10.0 2 200 0.02
08.30 Ie seq 2 9.0 ... 1250.0 A 1 201 30 A
08.31 Start mode seq 2 Voltage ramp, Torque ramp, Full voltage start 0 202 Voltage ramp
7
