134 Functions | Installation and commissioning manual | 1SFC132081M0201
Parameter
number
Description Setting range Number of
decimals
Fieldbus
ID
Default value Actual
setting
08.32 Start ramp time seq 2 1 ... 120 s 0 203 10 s
08.33 Start ramp init lvl seq 2 10 ... 99% 0 204 30%
08.34 Curr lim level seq 2 0.5 ... 7.5 x I
e
1 205 7.0 x I
e
08.35 Kick start seq 2 On / Off 0 206 Off
08.36 Kick start level seq 2 50 ... 100% 0 207 70%
08 Sequence start
08.37 Kick start time seq 2 0.20 ... 2.00 s 2 208 0.20 s
08.38 Torque limit lvl seq 2 20 ... 200% 0 209 150%
08.39 Torque tune seq 2 0 ... 1000% 0 210 100%
08.40 Torque ctrl gain seq 2 0.01 ... 10.00 2 211 0.02
08.60 Ie seq 3 9.0 ... 1250 A 1 212 30 A
08.61 Start mode seq 3 Voltage ramp, Torque ramp, Full voltage start 0 213 Voltage ramp
08.62 Start ramp time seq 3 1 ... 120 s 0 214 10 s
08.63 Start ramp init lvl seq 3 10 ... 99% 0 215 30%
08.64 Curr lim level seq 3 0.5 ... 7.5 x I
e
1 216 7.0 x I
e
08.65 Kick start seq 3 On / Off 0 217 Off
08.66 Kick start level seq 3 50 ... 100% 0 218 70%
08.67 Kick start time seq 3 0.2 ... 2.00 s 2 219 0.2 s
08.68 Torque limit lvl seq 3 20 ... 200% 0 220 150%
08.69 Torque tune seq 3 0 ... 1000% 0 221 100%
08.70 Torque ctrl gain seq 3 0.01 ... 10.0 2 222 0.02
09 Automatic restart
09.01 Auto-reset delay time 0 ... 3600 s 0 223 10 s
09.02 Auto-restart On / Off 0 224 Off
09.03 Auto-restart max attempts 1 ... 10 0 225 5
10 Internal IO
10.01 In0 function None, Reset, Enable, Slow speed forward,
Slow speed reverse, Motor heating, Stand-
still brake, Start reverse, User defined
protection, Emergency mode, Fieldbus
disable control, Start 1, Start 2, Start 3. *
0 130 Reset
10.02 In1 function 0 ... 15 * 0 131 None
10.03 In2 function 0 ... 15 * 0 132 None
10.04 K4 function None, Run, Top of ramp, Event group 0,
Event group 1, Event group 2, Event group
3, Event group 4, Event group 5, Event
group 6,
Sequence 1 RUN, Sequence 2 RUN,
Sequence 3 RUN, Sequence 1 TOR,
Sequence 2 TOR, Sequence 3 TOR,
Run reverse **
0 133 Run
10.05 K5 function 0 ... 17 ** 0 134 Top of ramp
10.06 K6 function None, Run, Top of ramp, Event group 0,
Event group 1, Event group 2, Event group
3, Event group 4, Event group 5, Event
group 6, Sequence 1 Run, Sequence 2 Run,
Sequence 3 Run
0 135 Event group 0
10.07 AO reference 0-10 mA, 0-20 mA, 4-20 mA, 0-10 V 0 137 4-20 mA
10.08 AO type Motor current [A], Mains voltage [V], Active
power [kW], Active power [HP], Reactive
power [kVAr], Apparent power [kVA], Active
energy [kWh], Reactive energy [kVArh], COS
[COS [ĭ], Motor temperature [%], Thyristor
temperature [%], Motor voltage [%]
0 138 Motor current
[A]
10.09 AO max value 0.0 ... 1000000.0 0 139 500
10.10 AO min value 0.0 ... 1000000.0 0 140 0
