ABB PSTX720 - Page 142

142 Functions | Installation and commissioning manual | 1SFC132081M0201
Parameter
number
Description Setting range Number of
decimals
Fieldbus
ID
Default value Actual
setting
28.39 Simulation load No load, Linear Load, Progressive load,
High inertia load
0 30 Progressive load
28.40 Simulation connection Auto, In line, Inside delta UI, Inside delta IU, Two
phase (L1 shorted), Two phase (L2 shorted), Two
phase (L2 shorted), Unknown
0
303
In line
28.41 System mode Normal, Demo, Small motor 0 31 Normal
28.42 Limp mode On / Off 0 25 Off
28.43 Motor connection Auto, In line, Inside delta UI, Inside delta IU, Two
phase (L1 shorted), Two phase (L2 shorted), Two
phase (L2 shorted), Unknown
0 27 Auto
28.44 Advanced User security code 0 0
28.45 Enable Advanced User login Yes / No 0 No
28.46 User security code 00
28.47 Enable secure settings Yes / No 0 No
28.48 Disable Service login Yes / No 0 No
28.49 Shunt fault trip time 0.1 ... 120.0 s 1 5.0 s
28.50 Shunt fault trip level 0.1 ... 100.0 % 1 3.0 %
28.51 Firing angle sweep On / Off 0 On
28.52 Auxiliary condition On / Off 0 Off
28.53 Flux threshold gain 1 0.000 ... 1.000 3 0.022
28.54 Flux threshold gain 2 0.000 ... 1.000 3 0.147
29 Pump clean
29.01 Pump clean reverse speed Fast jog, Jog, Creep
Jog
29.02 Pump clean reverse
strength
10 … 100 %
45 %
29.03 Pump clean forward start
mode
Voltage ramp, Torque ramp, Full voltage
start
Full voltage
start
29.04 Pump clean auto forward
time
1.0 … 100.0 s
5.0 s
29.05 Pump clean auto reverse
time
1.0 … 100.0 s
5.0 s
29.06 Pump clean brake
strength
10 … 100 %
45 %
29.07 Pump clean brake timeout 1.0 … 100.0 s
10.0 s
29.08 Pump clean stop mode
Voltage ramp and brake, Torque ramp and
brake, Dynamic brake
Torque ramp
and brake
7
