ABB PVS-175-TL Quick Installation Guide

41
EN
PVS-175-TL
Output protection
Anti-islanding Protection According to local standard
Maximum external AC overcurrent protection 200 A
Output overvoltage protection - Varistor (-S / -S2 models) Yes
Output overvoltage protection -
Modular surge arresters (-SX / -SX2 models)
Type 2
Operating performance
Maximum Efficiency (ηmax) 98.7%
Weighted Efficiency (EURO) 98.4%
Communication
Embedded communication interfaces
1x RS485, 2x Ethernet (RJ45), WLAN
(IEEE802.11 b/g/n @ 2,4 GHz)
User Interface 4 LEDs, Web User Interface, Mobile APP
Communication protocol Modbus RTU/TCP (Sunspec compliant)
Commissioning tool Web User Interface, Mobile APP
Remote monitoring services Aurora Vision® monitoring portal
Advanced features
Embedded logging, direct telemetry
data transferring to ABB cloud
Environmental
Ambient temperature range
-25...+60°C /-13...140°F with
derating above 40°C / 104 °F
Storage temperature -40°C...+85°C / -40°F...185°F
Relative Humidity 4…100 % with condensation
Typical noise emission pressure 65 dB(A) @ 1 m
Maximum operating altitude without derating 2000 m / 6560 ft
Environmental pollution degree
classification for external environments
3
Environmental class Outdoor
Climatic category according to IEC 60721-3-4 4K4H
Physical
Environmental Protection Rating IP 65 (IP54 for the cooling section)
Cooling System Forced air
Dimensions (H x W x D)
867x1086x419 mm / 34.2”x42.7”x16.5”
for -S, -SX model
867x1086x458 mm / 34.2”x42.7”x18.0”
for -S2, SX2 model
Weight
~76 kg / 167,5 lbs for power module ;
~77 kg / 169,7 lbs for Wiring box
Overall max ~153 kg / 337,2 lbs
Assembly System Mounting bracket support
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Insulation Level Transformerless
Marking CE
Safety, EMC and Radio Spectrum Standards
IEC/EN 62109-1, IEC/EN 62109-2,
EN 61000-6-2, EN 61000-6-4,
EN 61000-3-11, EN 61000-3-12, EN 301 489-1,
EN 301 489-17, EN 300 328, EN 62311
Grid standard
(check the availability with your sales channel)
CEI 0-16, UTE C 15 712-1, JORDAN IRR-DCC-MV,
BDEW, P.O. 12.3, DRRG D.4

ABB PVS-175-TL Specifications

General

Brand	ABB
Model	PVS-175-TL
Category	Inverter
Language	English
