1.5 Application layer Capabilities Current value If configurable, list methods
○ Fixed at 2048 PST or LHMI
(ApLayMaxRxSize)
● Configurable, range 20 to 2048
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
1.5.4 Time-out waiting for complete application layer fragment: Time-out if all frames of a message fragment are not received in the specified
time. Measured from time first frame of a fragment is received until the last frame is received.
● None None
○ Fixed at ms
○ Configurable, range _______ to _______ms
○ Configurable, selectable from ___,___,___ms
○ Configurable, other, describe:
○ Variable, explain:
1.5.5 Maximum number of objects allowed in a single control request for CROB (Group 12): Note: The current value of this outstation
parameter is available remotely using protocol object Group 0 Variation 216.
● Fixed at 10 (enter 0 if controls are not
supported for CROB)
10
○ Configurable, range ________ to _______
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
○ Variable, explain:
1.5.6 Maximum number of objects allowed in a single control request for Analog Outputs (Group 41):
● Fixed at 0 (enter 0 if controls are not
supported for analog outputs)
0
○ Configurable, range ________ to _______
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
○ Variable, explain:
1.5.7 Maximum number of objects allowed in a single control request for data sets (Groups 85, 86, 87):
● Fixed at 0 (enter 0 if controls are not
supported for Data Sets)
0
○ Configurable, range ________ to _______
○ Configurable, selectable from ____,____,____
○ Configurable, other, describe:
○ Variable, explain:
1.5.8 Supports mixed object groups (AOBs, CROBs and Data sets) in the same control request:
○ Not applicable - controls are not supported Yes
● Yes
○ No
Table continues on next page
Section 3 1MRK 511 419-UUS A
DNP3 protocol implementation
38 650 series 2.2 ANSI
Point list manual
