1.5 Application layer Capabilities Current value If configurable, list methods
1.5.9 Control Status Codes Supported: Indicates which control status codes are supported by the device:
• Masters must indicate which control status codes they accept in outstation responses
• Outstations must indicate which control status codes they generate in responses
Control status code 0 (success) must be supported by Masters and Outstations.
●1 – TIMEOUT
● 2 – NO_SELECT
● 3 – FORMAT_ERROR
● 4 – NOT_SUPPORTED
● 5 – ALREADY_ACTIVE
○ 6 – HARDWARE_ERROR
● 7 – LOCAL
● 8 – TOO_MANY_OBJS
● 9 – NOT_AUTHORIZED
● 10 – AUTOMATION_INHIBIT
○ 11 – PROCESSING_LIMITED
○ 12 – OUT_OF_RANGE
○ 13 – DOWNSTREAM_LOCAL
○ 14 – ALREADY_COMPLET
○ 15 – BLOCKED
○ 16 – CANCELLED
○ 17 – BLOCKED_OTHER_MASTER
○ 18 – DOWNSTREAM_FAIL
○ 126 – RESERVED
● 127 – UNDEFINED
Table 8: Fill out for outstations only
1.7 Fill out the
following items for
outstations only
Capabilities
Current value If configurable, list
methods
1.7.1 Time-out waiting for application confirm of solicited response message:
○ None 10 seconds PST or LHMI
(tApplConfTout)
○ Fixed at ms
● Configurable, range 0 to 300 ms
○ Configurable, selectable from ms
○ Configurable, other, describe:
○ Variable, explain:
Table continues on next page
1MRK 511 419-UUS A Section 3
DNP3 protocol implementation
650 series 2.2 ANSI 39
Point list manual
