Table 185. Maximum quantity of I/O modules

Note: When ordering I/O modules, observe the maximum quantities according to the table below

Case sizes BIM IOM BOM/

SOM

MIM Maximum in case

1/1 x 19”, one (1) TRM 14 6 4 4 14 cards, including a combination of four cards of type BOM, SOM and MIM

1/1 x 19”, two (2) TRM 11 6 4 4 11 cards, including a combination of four cards of type BOM, SOM and MIM

3/4 x 19”, one (1) TRM 8 6 4 4 8 cards, including a combination of four cards of type BOM, SOM and maximun oen

MIM

3/4 x 19”, two (2) TRM 5 5 4 4 5 cards, including a combination of four cards of type BOM, SOM and maximun oen

MIM

1/2 x 19”, one (1) TRM 3 3 3 1 3 cards
