Table 184. Analog system selection
Analog system Selection Notes and Rules
No first TRM included X 0 Note: Only the same type of TRM
(compression or ringlug) in the
same terminal.
Compression terminals A
Ringlug terminals B
First TRM 12I 1A, 50/60Hz 1
First TRM 12I 5A, 50/60Hz 2
First TRM 9I+3U 1A, 100/220V, 50/60Hz 3
First TRM 9I+3U 5A, 100/220V, 50/60Hz 4
First TRM 5I, 1A+4I, 5A+3U, 100/220V, 50/60Hz 5
First TRM 6I+6U 1A, 100/220V, 50/60Hz 6
First TRM 6I+6U 5A, 100/220V, 50/60Hz 7
First TRM 6I 1A, 50/60Hz 8
First TRM 6I 5A, 50/60Hz 9
First TRM 7I+5U 1A, 100/220V, 50/60Hz 12
First TRM 7I+5U 5A, 100/220V, 50/60Hz 13
First TRM 6I, 5A + 1I, 1A + 5U, 110/220V, 50/60Hz 14
First TRM 3I, 5A + 4I, 1A + 5U, 110/220V, 50/60Hz 15
First TRM 3I, 5A + 3I, 1A + 6U, 110/220V, 50/60Hz 16
First TRM 3IM, 1A + 4IP, 1A + 5U, 110/220V, 50/60Hz 17
First TRM 3IM, 5A + 4IP, 5A + 5U, 110/220V, 50/60Hz 18
First TRM 10I+2U, 1A, 110/220V, 50/60 Hz 19
First TRM 10I+2U, 5A, 110/220V, 50/60 Hz 20
No second TRM included X 0
Compression terminals A
Ringlug terminals B
Second TRM 12I 1A, 50/60Hz 1
Second TRM 12I 5A, 50/60Hz 2
Second TRM 9I+3U 1A, 100/220V, 50/60Hz 3
Second TRM 9I+3U 5A, 100/220V, 50/60Hz 4
Second TRM 5I, 1A+4I, 5A+3U, 100/220V, 50/60Hz 5
Second TRM 6I+6U 1A, 100/220V, 50/60Hz 6
Second TRM 6I+6U 5A, 100/220V, 50/60Hz 7
Second TRM 6I 1A, 50/60Hz 8
Second TRM 6I 5A, 50/60Hz 9
Second TRM 7I+5U 1A, 100/220V, 50/60Hz 12
Second TRM 7I+5U 5A, 100/220V, 50/60Hz 13
Second TRM 6I, 5A + 1I, 1A + 5U, 110/220V, 50/60Hz 14
Second TRM 3I, 5A + 4I, 1A + 5U, 110/220V, 50/60Hz 15
Second TRM 3I, 5A + 3I, 1A + 6U, 110/220V, 50/60Hz 16
Second TRM 3IM, 1A + 4IP, 1A + 5U, 110/220V, 50/60Hz 17
Second TRM 3IM, 5A + 4IP, 5A + 5U, 110/220V, 50/60Hz 18
Second TRM 10I+2U, 1A, 110/220V, 50/60 Hz 19
Second TRM 10I+2U, 5A, 110/220V, 50/60 Hz 20
Selected
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
102 ABB
