ABB REC670 2.1 IEC User Manual

Table 179. Casing selection
Casing Selection Notes and Rules
1/2 x 19" case A
3/4 x 19” case 1 TRM slot B
3/4 x 19" case 2 TRM slots C
1/1 x 19” case 1 TRM slot D
1/1 x 19" case 2 TRM slots E
Selected
Table 180. Mounting selection
Mounting details with IP40 of protection from the front Selection Notes and Rules
No mounting kit included X
19" rack mounting kit for 1/2 x 19" case of 2xRHGS6 or RHGS12 A
19" rack mounting kit for 3/4 x 19" case or 3xRGHS6 B
19" rack mounting kit for 1/1 x 19" case C
Wall mounting kit D Note: Wall mounting not
recommended with
communication modules with
fibre connection (SLM, OEM,
LDCM)
Flush mounting kit E
Flush mounting kit + IP54 mounting seal F
Selected
Table 181. Connection type
Connection type for Power supply module
Selection Notes and Rules
Compression terminals M
Ringlug terminals N
Connection type for Input/Output modules
Compression terminals P
Ringlug terminals R
Selected
Table 182. Auxiliary power supply
Selection Notes and Rules
24-60 VDC A
90-250 VDC B
Selected
Table 183. Human machine interface selection
Human machine hardware interface
Selection Notes and Rules
Medium size - graphic display, IEC keypad symbols B
Medium size - graphic display, ANSI keypad symbols C
Selected
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
