Table 171. Scheme communication functions
Function Function
identication
Ordering no Positi
on
Available
qty
Selected
qty
Notes and
rules
Scheme communication logic for distance or Overcurrent protection ZCPSCH 1MRK005920-AA 1 0-1
Current reversal and weak-end infeed logic for distance protection ZCRWPSCH 1MRK005920-CA 3 0-1
Local acceleration logic ZCLCPSCH 1MRK005920-EA 5 0-1
Scheme communication logic for residual overcurrent protection ECPSCH 1MRK005920-FA 6 0-1
Current reversal and weakend infeed logic for residual overcurrent
protection
ECRWPSCH 1MRK005920-GA 7 0-1
Table 172. Logic
Position 1 2
L
Table 173. Logic functions
Function Function
identication
Ordering no Positi
on
Available
qty
Selected
qty
Notes and
rules
Configurable logic blocks Q/T 1MRK005922-MX 1 0-1
Extension logic package 1MRK005922-AY 2 0-1
Table 174. Monitoring
Position 1 2
M
Table 175. Monitoring functions
Function
Function
identication
Ordering no Positi
on
Available
qty
Selected
qty
Notes and
rules
Circuit breaker condition monitoring SSCBR 1MRK005924-HA 1 00-18
Fault locator LMBRFLO 1MRK005925-XB 2 0-1
Table 176. Station communication
Position
1 2 3 4 5 6 7 8 9 10 11 12 13
P 0 0 0 0 0 0 0 0 0 0 0
Table 177. Station communication functions
Function
Function
identication
Ordering no Position Available qty Selected
qty
Notes and
rules
Process Bus communication IEC 61850-9-2 1MRK005930-TA 1 0 if F00 is
selected, 6 if N00
is selected
Note:
REC670
customized
qty = 0,
REC670
61850-9-2 qty
= 6
IEC 62439-3 parallel redundancy protocol PRP 1MRK002924-YB 2 0-1 Note: Not
valid in
REC670
61850-9-2LE
product
Note:
Requires 2–
channel OEM
Table 178. Language selection
First local HMI user dialogue language
Selection Notes and Rules
HMI language, English IEC B1
Additional HMI language
No additional HMI language X0
HMI language, English US A12
Selected
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
100 ABB
