ABB REC670 2.1 IEC User Manual

Table 169. Control functions
Function Function
identication
Ordering no Positi
on
Available
qty
Selected
Qty
Notes and
rules
Synchrocheck, energizing check and synchronizing SESRSYN 1MRK005917-AA 1 0-2 Rule: Can
only be
ordered
with
Apparatus
control
APC10/
APC15
Synchrocheck, energizing check and synchronizing SESRSYN 1MRK005917-XA 2 0-6 Rule: Can
only be
ordered
with
Apparatus
control
APC30
Autorecloser SMBRREC 1MRK005917-BA 3 0-4 Rule: Can
only be
ordered
with
Apparatus
control
APC10/
APC15
Autorecloser SMBRREC 1MRK005917-XB 4 0-6 Rule: Can
only be
ordered
with
Apparatus
control
APC30
Apparatus control for single bay, max 10 app. (1CB) incl. Interlocking APC10 1MRK005917-AY 5 0-1 Note: One
of
Apparatus
control
APC10,
APC15 or
APC30
must be
ordered.
Apparatus control for single bay, max 15 app. (2CBs) incl. Interlocking APC15 1MRK005917-BY 6 0-1
Apparatus control for up to 6 bays, max 30 app. (6CBs) incl.
Interlocking
APC30 1MRK005917-CY 7 0-1
Automatic voltage control for tapchanger, single control TR1ATCC 1MRK005917-NB 8 0-4 Note: Only
one TCC
may be
selected.
Note: If
TR1ATCC
or
TR8ATCC
is ordered
then one
of
TCMYLTC
or
TCLYLTC
must be
ordered.
Automatic voltage control for tapchanger, parallel control TR8ATCC 1MRK005917-PB 9 0-4
Tap changer control and supervision, 6 binary inputs TCMYLTC 1MRK005917-DB 10 0-4
Tap changer control and supervision, 32 binary inputs TCLYLTC 1MRK005917-EA 11 0-4
Table 170. Scheme communication
Position
1 2 3 4 5 6 7 8
K 0 0 0
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
ABB 99
