ABB REC670 2.1 IEC User Manual

GUID-94C803B4-6C5A-4072-AB5C-20DDE98C9A70 v1
Table 88. Number of RSMEMORYQT instances
Logic block Quantity with cycle time
3 ms 8 ms 100 ms
RSMEMORYQT - 10 30
GUID-341562FB-6149-495B-8A63-200DF16A5590 v1
Table 89. Number of SRMEMORYQT instances
Logic block Quantity with cycle time
3 ms 8 ms 100 ms
SRMEMORYQT - 10 30
GUID-B6231B97-05ED-40E8-B735-1E1A50FDB85F v1
Table 90. Number of TIMERSETQT instances
Logic block Quantity with cycle time Range or Value Accuracy
3 ms 8 ms 100 ms
TIMERSETQT - 10 30 (0.000–90000.000) s ±0.5% ±10 ms
GUID-1C381E02-6B9E-44DC-828F-8B3EA7EDAA54 v1
Table 91. Number of XORQT instances
Logic block Quantity with cycle time
3 ms 8 ms 100 ms
XORQT - 10 30
GUID-19810098-1820-4765-8F0B-7D585FFC0C78 v6
Table 92. Number of instances in the extension logic package
Logic block Quantity with cycle time
3 ms 8 ms 100 ms
AND 40 40 100
GATE - - 49
INV 40 40 100
LLD - - 49
OR 40 40 100
PULSETIMER 5 5 49
SLGAPC 10 10 54
SRMEMORY - - 110
TIMERSET - - 49
VSGAPC 10 10 110
XOR - - 49
GUID-65A2876A-F779-41C4-ACD7-7662D1E7F1F2 v1
Table 93. Number of B16I instances
Function Quantity with cycle time
3 ms 8 ms 100 ms
B16I 6 4 8
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
ABB 77
