ABB REC670 2.1 IEC User Manual

GUID-3820F464-D296-4CAD-8491-F3F997359D79 v1
Table 94. Number of BTIGAPC instances
Function Quantity with cycle time
3 ms 8 ms 100 ms
BTIGAPC 4 4 8
GUID-B45901F4-B163-4696-8220-7F8CAC84D793 v1
Table 95. Number of IB16 instances
Function Quantity with cycle time
3 ms 8 ms 100 ms
IB16 6 4 8
GUID-A339BBA3-8FD0-429D-BB49-809EAC4D53B0 v1
Table 96. Number of ITBGAPC instances
Function Quantity with cycle time
3 ms 8 ms 100 ms
ITBGAPC 4 4 8
GUID-B258726E-1129-47C9-94F9-BE634A2085FA v3
Table 97. Elapsed time integrator with limit transgression and overow supervision TEIGAPC
Function Cycle time (ms) Range or value Accuracy
Elapsed time integration 3 0 ~ 999999.9 s ±0.2% or ±20 ms whichever is
greater
8 0 ~ 999999.9 s ±0.2% or ±100 ms whichever is
greater
100 0 ~ 999999.9 s ±0.2% or ±250 ms whichever is
greater
Table 98. Number of TEIGAPC instances
Function
Quantity with cycle time
3 ms 8 ms 100 ms
TEIGAPC 4 4 4
GUID-F5E124E3-0B85-41AC-9830-A2362FD289F2 v1
Table 99. Running hour-meter TEILGAPC
Function Range or value Accuracy
Time limit for alarm supervision, tAlarm (0 - 99999.9) hours ±0.1% of set value
Time limit for warning supervision, tWarning (0 - 99999.9) hours ±0.1% of set value
Time limit for overflow supervision Fixed to 99999.9 hours ±0.1%
1MRK 511 361-BEN B
Bay control REC670 2.1 IEC
Product version: 2.1
78 ABB
