R
X
X1OutFw
X1InFw
1
RLdOutFw
RLdInFw
RLdOutRv
RLdInRv
2
3
4
X1InRv
IEC09000226_1_en.vsd
IEC09000226 V1 EN-US
Figure 37: Operating principle and characteristic of the power swing detection
function (settings parameters in italic)
Where:
RLdInFw =
RLdOutFw · kLdRFw
RLdInRv =
RLdOutRv · kLdRRv
X1OutFw =
X1InFw + (RLdOutFw -
RLdInFw)
X1OutRv =
X1InRv + (RLdOutFw -
RLdInFw)
11.4.9.1 Verifying the settings
M13888-11 v6
Preconditions
The following output signal shall be configured to binary output available: ZOUT,
measured impedance within outer impedance boundary
.
