IEC 61850 or
function name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33) RED670 (A42) RED670 (B42)
RED670 (C42)
RANGE_XP Measured value expander block 66 66 66 66 66
SSIMG 63 Insulation supervision for gas
medium
21 21 21 21 21
SSIML 71 Insulation supervision for liquid
medium
3 3 3 3 3
SSCBR Circuit breaker condition
monitoring
0-6 6 3 6 3
LMBRFLO Fault locator 1 1 1 1 1
I103MEAS Measurands for IEC
60870-5-103
1 1 1 1 1
I103MEASUSR Measurands user defined
signals for IEC 60870-5-103
3 3 3 3 3
I103AR Function status auto-recloser
for IEC 60870-5-103
1 1 1 1 1
I103EF Function status earth-fault for
IEC 60870-5-103
1 1 1 1 1
I103FLTPROT Function status fault protection
for IEC 60870-5-103
1 1 1 1 1
I103IED IED status for IEC 60870-5-103 1 1 1 1 1
I103SUPERV Supervison status for IEC
60870-5-103
1 1 1 1 1
I103USRDEF Status for user defined signals
for IEC 60870-5-103
20 20 20 20 20
L4UFCNT Event counter with limit
supervision
30 30 30 30 30
TEILGAPC Running hour meter 6 6 6 6 6
Metering
PCFCNT Pulse-counter logic 16 16 16 16 16
ETPMMTR Function for energy calculation
and demand handling
6 6 6 6 6
1MRK 505 378-UEN A Section 3
Available functions
