ABB REF 542plus Technical Reference Manual

55
NUMBER CODE DESCRIPTION
16 750170/854 3 sensors + 3 CT + 1 CT/0.2 A + 1 VT
17 750170/855 3 sensors + 3 CT + 1 CT/0.2 A + 1 CT/0.2 A
Table 7.-9 Mix of transformers
NUMBER CODE DESCRIPTION
30 750170/804 3 CT + 3 VT + 1 CT/0.2 A + 1 VT
31 750170/806 3 VT + 3 VT + 1 CT/0.2 A + 1 CT/0.2 A
32 750170/807 3 CT + 3 CT
33 750170/809 3 CT + 3 CT + 1 CT/0.2 A + 1 VT
34 750170/812 3 VT + 3 VT + 1 VT
35 750170/817 3 CT + 3 VT + 1 CT
36 750170/819 3 CT + 3 VT + 1 CT + 1 VT
37 750170/821 3 CT + 0 VT + 1 CT
38 750170/822 3 CT + 0 VT + 1 CT/0.2 A
39 750170/825 3 CT + 3 VT + 1 CT/0.2 A + 1 CT/0.2 A
40 750170/826 3 CT + 3 VT + 1 VT + 1 VT
41 750170/827 3 CT + 3 CT + 1 CT + 1 CT
42 750170/828 3 CT + 3 CT + 1 CT + 1 VT
43 750170/824 3 CT + 3 VT + 1 CT + 1 CT
76B6A33303 6 SZ41
Table 7.-10 Communication (with optional communication module)
NUMBER CODE NAME DESCRIPTION
E 1VCR009634001 IEC 61850/MODBUS TCP
with RJ45
F 1VCR009634002 IEC 61850/MODBUS TCP
with LC optical connector
N none Without communication No communication is
requested
1 750079/801 Modbus RTU / SPA RS
485
2 750079/802 Modbus RTU / SPA glass
fibre with ST connectors
3 701842/801 SPA plastic fibre
4 701842/802 SPA glass fibre with SMA
connectors
5 701842/803 SPA glass fibre with ST
connectors
6 750071/801 LON - LAG 1.4
7 750071/803 IEC 60870-5-103
76B6A333036S Z41
Multifunction Protection and Switchbay Control
Unit
Technical Reference Manual
REF 542plusREF 542plus
1MRS755859
