ABB REF 542plus Technical Reference Manual

Table 7.-11 Enclosure versions
NUMBER CODE NAME DESCRIPTION
S 750154/801 Normal base unit Normal version
W 750102/801 Wide base unit Wide version
76B6A333036SZ 41
Table 7.-12 HMI variations
NUMBER CODE NAME DESCRIPTION
N none No HMI
A 007346/003 HMI V5 - IEC, auxiliary
voltage 48-90 V DC
B 007346/004 HMI V5 - IEC, auxiliary
voltage 110-240 V DC
C 007346/007 HMI V5 - IEC, external cover,
auxiliary voltage 48-90 V DC
D 007346/008 HMI V5 - IEC, external cover,
auxiliary voltage 110-240 V
DC
E 007346/011 HMI V5 - IEC, Chinese,
auxiliary voltage 48-90 V DC
F 007346/012 HMI V5 - IEC, Chinese,
auxiliary voltage 110-240 V
DC
G 007346/015 HMI V5 - IEC, Chinese,
external cover, auxiliary
voltage 48-90 V DC
H 007346/016 HMI V5 - IEC, Chinese,
external cover, auxiliary
voltage 110-240 V DC
76B6A333036SZ4 1
Table 7.-13 Connection cables between the HMI and the base unit
1)
NUMBER CODE NAME DESCRIPTION
N none No cable No cable
1 750142/801 HMI cable - 1.8 m 1.8 m cable with corresponding
connectors
2 750142/817 HMI cable - 2.5 m 2.5 m cable with corresponding
connectors
3 750142/818 HMI cable - 3.5 m 3.5 m cable with corresponding
connectors
4 750142/819 HMI cable - 4.5 m 4.5 m cable with corresponding
connectors
56
REF 542plusREF 542plus
Multifunction Protection and Switchbay Control
Unit
Technical Reference Manual
1MRS755859
