1MDU07212-YN Rev. C Section 6
Installation
REF601 / REJ601 69
Application Manual
Table 32: Binary Output configuration, continue
Signal to
activate output
BO1 BO2 BO3 BO4 BO5 BO6
3Ith > Alm
3Ith> Blkcl
I2/I1> Str
I2> Start
Trip : I> / 51 (x) (x) (x)
Trip : I>> / 50-1 (x) (x) (x)
Trip : I>>> / 50-2 (x) (x) (x)
Trip : Io> / 51N (x) (x) (x)
Trip : Io> / 50N (x) (x) (x)
3Ith > Trip
I2/I1> Trip
I2> Trip
BF Stage1
BF Stage2
BF RecTrip
O->I Close
O->I InPro
O->I FinalTr
O->I Blocked
Signal 1
Signal 2
Signal 3
CB Open Command (x) (x)
CB Close Command (x)
TCS Fault
Unit Ready (x)
Output behavior : “-“ = Non inverted, “I” = Inverted
Remark : “(..)” = Default setting
To Next Page
