ABB REL 356 Current Differential Protection
2-17
Installation, Operation and Maintenance
Table 2-4. Target (Fault Data) Information Continued
DKM Fault distance in kilometers XXX.X km
PFLC Pre-fault load current XXX.X amps
PFLV Pre-fault voltage XXX.X volts
LP Pre-fault load angle XXX.X deg
VAG VAG fault voltage magnitude
VAG fault voltage angle
XXX.X
XXX.X
volts
deg
VBG VBG fault voltage magnitude
VBG fault voltage angle
XXX.X
XXX.X
volts
deg
VCG VCG fault voltage magnitude
VCG fault voltage angle
XXX.X
XXX.X
volts
deg
3V0 3V0 fault voltage magnitude
3V0 fault voltage angle
XXX.X
XXX.X
volts
deg
Target Description Format Units
IA IA fault voltage magnitude
IA fault voltage angle
XXX.X
XXX.X
amps
deg
IB IB fault voltage magnitude
IB fault voltage angle
XXX.X
XXX.X
volts
deg
IC IC fault voltage magnitude
IC fault voltage angle
XXX.X
XXX.X
amps
deg
3I0 3I0 fault voltage magnitude
3I0 fault voltage angle
XXX.X
XXX.X
volts
deg
Notes: The "YES/NO" targets are displayed only if they are "YES". The
impedance is dependent upon the CTYP setting. The internal
impedance values are for a 5A ct. The impedance value is multiplied
by 5 if a 1 A ct is used (CTYP = 1). The angles are not displayed if the
magnitude of the value or the reference is less than 0.5 a or 0.7 rms.
*
**
9600 bps Audio Tone Channel
56/64 kbps Digital Communication
DATE Date of fault (month.day) MM.DD
YEAR Year of fault YYYY
TIME Time of fault (hours.minutes) HH.MM
SEC Time of fault (seconds) XXXX sec
MSEC Time of fault (milliseconds) XXXX msec
LDT LDT used at the time of trip XXX.X msec
XMTR Channel transmit level XXXX dBm
*RCVR Channel receive level XXXX dBm
*SNR Channel signal-to-noise ratio XXXX dB
**FEPH Channel error XXXX/FAIL
