For parameters with defined steps, digits smaller than the step
value cannot be edited.
3.
Press
or to move the cursor to another digit.
4. To select the minimum or maximum value, select the arrow symbol in front of
the value.
•
To set the value to the maximum, press
.
•
To set the value to the minimum, press .
A070756 V3 EN
Figure 30: Arrow symbol is active, the value is set to the maximum
After pressing , the previous value can be restored by pressing once, and
vice versa. Another press of or sets the value to the lower or higher limit.
The symbol in front of the value is ↕, when the previous value is shown.
A070757 V3 EN
Figure 31: Restoring the previous value
4.1.14.2 Editing string values
1. Activate the setting mode and select a setting.
Section 4 1MRS758754 B
Using the HMI
54 REC615 and RER615
Operation Manual
