Section 1 1MAC254287-MB B
Introduction
8 REM615 ANSI
Point List Manual
Trip circuit supervision, instance 1 TCSSCBR1 TCM-1 TCS(1)
Trip circuit supervision, instance 2 TCSSCBR2 TCM-2 TCS(2)
Current circuit supervision CCRDIF1 CCM MCS 3I
Fuse Failure supervision, instance 1 SEQRFUF1 60 FUSEF(1)
Runtime counter for machines and devices,
instance 1
MDSOPT1 OPTM-1 OPTS(1)
Runtime counter for machines and devices,
instance 2
MDSOPT2 OPTM-2 OPTS(2)
Measurement
Three-phase current measurement, instance 1 CMMU1 IA, IB, IC 3I
Three-phase current measurement, instance 2 CMMU2 IA, IB, IC (2) 3I(B)
Sequence current measurement, instance 1 CSMSQI1 I1, I2, I0 I1, I2, I0
Sequence current measurement, instance 2 CSMSQI2 I1, I2, I0 (2) I1, I2, I0(B)
Residual current measurement, instance 1 RESCMMU1 IG Io
Three-phase voltage measurement, instance 1 VMMU1 VA, VB, VC 3U
Residual voltage measurement RESVMMU1 VG Uo
Sequence voltage measurement, instance 1 VSMSQI1 V1, V2, V0 U1, U2, U0
Single-phase power and energy measurement,
instance 1
SPEMMU1 SP, SE SP, SE
Three-phase power and energy measurement,
instance 1
PEMMU1 P, E P, E
Recorder
Disturbance recorder RDRE1 DFR -
Fault recorder FLTMSTA1 FR -
Sequence event recorder SER SER -
Other Functions
Minimum pulse timer (2 pcs), instance 1 TPGAPC1 TP - 1 TP (1)
Minimum pulse timer (2 pcs), instance 2 TPGAPC2 TP - 2 TP (2)
Minimum pulse timer (2 pcs), instance 3 TPGAPC3 TP - 3 TP (3)
Minimum pulse timer (2 pcs), instance 4 TPGAPC4 TP - 4 TP (4)
Pulse timer (8 pcs), instance 1 PTGAPC1 PT-1 PT (1)
Pulse timer (8 pcs), instance 2 PTGAPC2 PT-2 PT (2)
Time delay off (8 pcs), instance 1 TOFGAPC1 TOF-1 TOF (1)
Time delay off (8 pcs), instance 2 TOFGAPC2 TOF-2 TOF (2)
Time delay on (8 pcs), instance 1 TONGAPC1 TON -1 TON (1)
Time delay on (8 pcs), instance 2 TONGAPC2 TON -2 TON (2)
Set reset (8 pcs), instance 1 SRGAPC1 SR-1 SR (1)
Set reset (8 pcs), instance 2 SRGAPC2 SR-2 SR (2)
Move (8 pcs), instance 1 MVGAPC1 MV-1 MV (1)
Move (8 pcs), instance 2 MVGAPC2 MV-2 MV (2)
Standard configuration functionality IEC 61850 ANSI/C37.2 IEC60617
