ABB REM615 List Manual

1MAC254287-MB B Section 2
DNP3 data mappings
REM615 ANSI 9
Point List Manual
Section 2 DNP3 data mappings
2.1 Overview
This document describes the DNP3 data points and structures available in REM615 Ver.
4.0 ANSI.
The point tables show all the available DNP3 data points in this IED. The data objects in
the point tables are listed based on the IEC61850 logical node name. Also the default point
indexes, class assignments and scaling configurations are shown. The DNP3 points can be
freely added, removed, reorganized and reconfigured using PCM600.
This list represents the superset of DNP3 points. The actual set of available points is
determined by the IED's ordercode. A “Yes” in a “No Events” column indicates that no
events can be generated for that point regardless of class assignment. A “No” in “Enabled”
column indicates that the point is not active. Inactive points can be made active through
PCM600.
2.2 Binary/Analog Inputs
Table 2: General Device Information (LLN0)
Table 3: Device Physical Information (LPHD1)
DNP
Object
Type
No
Event
Point
Index
DNP Class
Enable
d
Description
Scale
Factor
IEC61850 Data Attribute Name
BI 0 Class 1 and 0 Yes Protection LLN0 Settings Reservation LD0.LLN0.SetSeld.stVal
BI 1 Class 1 and 0 Yes Protection LLN0 Settings Change LD0.LLN0.SetChg.stVal
BI 588 Class 1 and 0 Yes Local / Remote (1- Local; 0-Remote) CTRL.LLN0.Loc.stVal
BI Yes 604 Class 0 Yes Protection LLN0 Reset all power quality data LD0.LLN0.PQRs.stVal
AI 406 Class 2 and 0 Yes Local / Remote state 0 CTRL.LLN0.LocRem.stVal
DNP
Object
Type
No
Event
Point
Index
DNP Class Enabled Description
Scale
Factor
IEC61850 Data Attribute Name
BI Yes 2 Class 0 Yes Physical Device Reset Device LD0.LPHD1.RsDev.stVal
AI 0 Class 2 and 0 Yes General Device State 0 LD0.LPHD1.PhyHealth.stVal
AI 1 Class 2 and 0 Yes Physical Sevice Warning 0 LD0.LPHD1.PhyHealth1.stVal
AI Yes 2 Class 0 Yes Number Of Power Ups 0 LD0.LPHD1.NumPwrUp.stVal
AI Yes 3 Class 0 Yes Number Of Warm Starts 0 LD0.LPHD1.WrmStr.stVal
AI Yes 4 Class 0 Yes Number Of Watchdog Device Resets 0 LD0.LPHD1.WacTrg.stVal
AI 402 Class 2 and 0 Yes Internal Fault 1 LD0.LPHD1.PhyHealth2.stVal
