ABB REM615 - Symbols and conventions

1MAC254287-MB B Section 1
Introduction
REM615 ANSI 7
Point List Manual
1.4.3 Functions, codes and symbols
Table 1: Functions included in standard configurations
Standard configuration functionality IEC 61850 ANSI/C37.2 IEC60617
Protection
Three-phase non-directional overcurrent
protection, low stage, instance 1
PHLPTOC1 51P 3I> (1)
Three-phase non-directional overcurrent
protection, high stage, instance 1
PHHPTOC1 50P 3I>> (1)
Non-directional ground-fault protection, low stage,
instance 1
EFLPTOC1 51G Io> (1)
Non-directional ground-fault protection, high
stage, instance 1
EFHPTOC1 50G Io>> (1)
Directional ground-fault protection, low stage,
instance 1
DEFLPDEF1 67/51N Io> -> (1)
Residual overvoltage protection, instance 1 ROVPTOV1 59G Uo> (1)
Residual overvoltage protection, instance 2 ROVPTOV2 59N Uo> (2)
Three-phase under-voltage protection, instance 1 PHPTUV1 27 3U< (1)
Three-phase overvoltage protection, instance 1 PHPTOV1 59 3U> (1)
Positive-sequence undervoltage protection,
instance 1
PSPTUV1 27PS U1<(1)
Negative-sequence overvoltage protection,
instance 1
NSPTOV1 47 U2>(1)
Frequency protection, instance 1 FRPFRQ1 81 f>/f<,df/dt(1)
Negative-sequence overcurrent protection for
motors, instance 1
MNSPTOC1 46M-1 I2>M(1)
Negative-sequence overcurrent protection for
motors, instance 2
MNSPTOC2 46M-2 I2>M(2)
Loss of load supervision, instance 1 LOFLPTUC1 37M-1 3I<(1)
Loss of load supervision, instance 2 LOFLPTUC2 37M-2 3I<(2)
Motor load jam protection JAMPTOC1 51LR Ist>
Motor start-up supervision STTPMSU1 66/51LRS Is2t n<
Phase reversal protection PREVPTOC1 46R I2>>
Thermal overload protection for motors MPTTR1 49M 3Ith>M
Motor differential protection MPDIF1 87M 3dl>M
Circuit breaker failure protection, instance 1 CCBRBRF1 50BF 3I>/Io>BF(1)
Master trip, instance 1 TRPPTRC1 86/94-1 Master Trip(1)
Master trip, instance 2 TRPPTRC2 86/94-2 Master Trip (2)
Arc protection, instance 1 ARCSARC1 AFD-1 ARC (1)
Arc protection, instance 2 ARCSARC2 AFD-2 ARC (2)
Arc protection, instance 3 ARCSARC3 AFD-3 ARC (3)
Control
Circuit-breaker control, instance 1 CBCBR1 52 I <-> O CB (1)
Emergency startup ESMGAPC1 62EST ESTART
Condition Monitoring
Circuit-breaker condition monitoring, instance 1 SSCBR1 52CM CBCM(1)
