ABB REM615 List Manual

1MAC254287-MB B Section 2
DNP3 data mappings
REM615 ANSI 35
Point List Manual
2.3 DNP Binary Outputs
Table 91: DNP binary outputs
DNP
Object
Type
No
Event
Point
Index
DNP Class Enabled Description
Scale
Factor
IEC61850 Data Attribute Name
BO 0 Yes Reset Indications Leds LD0.LLN0.LEDRs1.Oper.ctlVal
BO 1 Yes Reset Programmable Leds LD0.LLN0.LEDRs2.Oper.ctlVal
BO 2 Yes Reset Device LD0.LPHD1.RsDev.Oper.ctlVal
BO 3 Yes 52CM Reset Accumulation Energy LD0.SSCBR1.RsAccAPwr.Oper.ctlVa
l
BO 4 Yes 52CM Reset Input For Cb Remaining
Life And Operation Counter
LD0.SSCBR1.RsCBWear.Oper.ctlVal
BO 5 Yes 52CM Reset Recloser Travel Time LD0.SSCBR1.RsTrvTm.Oper.ctlVal
BO 6 Yes 52CM Reset Spring Charging Time LD0.SSCBR1.RsSprChaTm.Oper.ctl
Val
BO 9 Yes X130-Output 1 LD0.XGGIO130.SPCSO1.Oper.ctlVal
BO 10 Yes X130-Output 2 LD0.XGGIO130.SPCSO2.Oper.ctlVal
BO 11 Yes X130-Output 3 LD0.XGGIO130.SPCSO3.Oper.ctlVal
BO 12 Yes X110-Output 1 LD0.XGGIO110.SPCSO1.Oper.ctlVal
BO 13 Yes X110-Output 2 LD0.XGGIO110.SPCSO2.Oper.ctlVal
BO 14 Yes X110-Output 3 LD0.XGGIO110.SPCSO3.Oper.ctlVal
BO 15 Yes X110-Output 4 LD0.XGGIO110.SPCSO4.Oper.ctlVal
BO 16 Yes X100-Output 1 LD0.XGGIO100.SPCSO1.Oper.ctlVal
BO 17 Yes X100-Output 2 LD0.XGGIO100.SPCSO2.Oper.ctlVal
BO 18 Yes X100-Output 3 LD0.XGGIO100.SPCSO3.Oper.ctlVal
BO 19 Yes X100-Output 4 LD0.XGGIO100.SPCSO4.Oper.ctlVal
BO 20 Yes X100-Output 5 LD0.XGGIO100.SPCSO5.Oper.ctlVal
BO 21 Yes X100-Output 6 LD0.XGGIO100.SPCSO6.Oper.ctlVal
BO 22 Yes Led 1 Control LD0.LEDGGIO1.SPCSO1.Oper.ctlVa
l
BO 23 Yes Led 2 Control LD0.LEDGGIO1.SPCSO2.Oper.ctlVa
l
BO 24 Yes Led 3 Control LD0.LEDGGIO1.SPCSO3.Oper.ctlVa
l
