DNP3 data mappings
36 REM615 ANSI
Point List Manual
BO 25 Yes Led 4 Control LD0.LEDGGIO1.SPCSO4.Oper.ctlVa
l
BO 26 Yes Led 5 Control LD0.LEDGGIO1.SPCSO5.Oper.ctlVa
l
BO 27 Yes Led 6 Control LD0.LEDGGIO1.SPCSO6.Oper.ctlVa
l
BO 28 Yes Led 7 Control LD0.LEDGGIO1.SPCSO7.Oper.ctlVa
l
BO 29 Yes Led 8 Control LD0.LEDGGIO1.SPCSO8.Oper.ctlVa
l
BO 30 Yes Led 9 Control LD0.LEDGGIO1.SPCSO9.Oper.ctlVa
l
BO 31 Yes Led 10 Control LD0.LEDGGIO1.SPCSO10.Oper.ctlV
al
BO 32 Yes Led 11 Control LD0.LEDGGIO1.SPCSO11.Oper.ctlV
al
BO 33 Yes IA IB IC (1) Reset Max Demands
Source
LD0.CMSTA1.RecRs.Oper.ctlVal
BO 34 Yes IA IB IC (2) Reset Max Demands
Source
LD0.CMSTA2.RecRs.Oper.ctlVal
BO 35 Yes P E Reset Of Accumulated Energy
Readings
LD0.PEMMTR1.SupDmdRs.Oper.ctl
Val
BO 36 Yes Reset Fault Records LD0.FLTMSTA1.RecRs.Oper.ctlVal
BO 47 Yes SP SE Reset of accumulated energy
readings
LD0.SPEMMTR1.SupDmdRs.Oper.ct
lVal
BO 49 Yes 52 Recloser-1 Switch Control CTRL.CBCSWI1.Pos.Oper.ctlVal
BO 51 Yes DFR Trig Recording DR.RDRE1.RcdTrg.Oper.ctlVal
BO 52 Yes DFR Disturbance Records DR.RDRE1.MemClr.Oper.ctlVal
BO 53 Yes Reset all power quality data LD0.LLN0.PQRs.Oper.ctlVal
BO 54 Yes 86/94-1 Clear Lockout Master Trip 1 LD0.TRPPTRC1.LORs.Oper.ctlVal
BO 55 Yes 86/94-1 Clear Master Trip1 LD0.TRPPTRC1.TrRs.Oper.ctlVal
BO 56 Yes 86/94-2 Clear Lockout Master Trip 2 LD0.TRPPTRC2.LORs.Oper.ctlVal
BO 57 Yes 86/94-2 Clear Master Trip2 LD0.TRPPTRC2.TrRs.Oper.ctlVal
BO 65 Yes OPTM-1 Clear operation time LD0.MDSOPT1.OpTmRs.Oper.ctlVal
BO 66 Yes OPTM-2 Clear operation time LD0.MDSOPT2.OpTmRs.Oper.ctlVal
BO 68 Yes 66/51LRS Reset number of motor
start-ups counter
LD0.STTPMRI1.RsStUpCnt.Oper.ctl
Val
BO 69 Yes 49M Clear temperature LD0.MPTTR1.RsTmp.Oper.ctlVal
