Section 3 1MAC254287-MB B
DNP3 protocol implementation
42 REM615 ANSI
Point List Manual
32 4 (default) 16-bit
analog
change
event with
time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
50 0 Time and
date
50 1 (default) Time and
date
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07 (limited qty = 1l)
08 (limited qty)
129 (response) 00, 01 (start-stop)
17, 28 (index)
2 (write) 07 (limited qty = 1l)
50 3 Time and
date last
recorded
time
2 (write) 07 (limited qty)
51 1 Time and
date CTO
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
51 2 Unsynchro
nized time
and date
CTO
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
52 2 Time delay
fine
129 (response) 07 (limited qty)
(qty = 1)
60 0 Not
defined
60 1 Class 0
data
1 (read) 06 (no range, or all)
60 2 Class 1
data
1 (read) 06 (no range, or all)
20 (enbl. unsol.)
21 (dab. unsol.)
22 (assign class)
07, 08 (limited qty)
06 (no range, or all)
60 3 Class 2
data
1 (read) 06 (no range, or all)
07, 08 (limited qty)
20 (enbl. unsol.)
21 (dab. unsol.)
22 (assign class)
06 (no range, or all)
60 4 Class 3
data
1 (read) 06 (no range, or all)
07, 08 (limited qty)
20 (enbl. unsol.)
21 (dab. unsol.)
22 (assign class)
06 (no range, or all)
80 1 Internal
indications
1 (read) 00, 01 (start-stop)
2 (write)
3
00 (start-stop)
index=7
No object (function code only) 13 (cold restart)
4
No object (function code only) 14 (warm restart)
No object (function code only) 23 (delay meas.)
No object (function code only) 24 (record current time)
1. A default variation refers to the variation responded when variation 0 is requested and/or in class 0, 1, 2, or 3 scans. Default variations are
configurable; however, default settings for the configuration parameters are indicated in the table above.
OBJECT REQUEST (Library will parse) RESPONSE (Library will respond with)
