Table 36. Distance protection (DSTPDIS) main settings, continued
Parameter Function Value (Range) Step
Directional mode Zn3 DSTPDIS 1 = Non-directional
2 = Forward
3 = Reverse
-
R1 zone 3 DSTPDIS 0.00...3000.00 Ω 0.01
X1 zone 3 DSTPDIS 0.00...3000.00 Ω 0.01
X1 reverse zone 3 DSTPDIS 0.00...3000.00 Ω 0.01
Z1 zone 3 DSTPDIS 0.01...3000.00 Ω 0.01
Z1 angle zone 3 DSTPDIS 15.0...90.0° 0.1
Z1 reverse zone 3 DSTPDIS 0.00...3000.00 Ω 0.01
PP operate delay Zn3 DSTPDIS 20...60000 ms 1
R0 zone 3 DSTPDIS 0.00...3000.00 Ω 0.01
X0 zone 3 DSTPDIS 0.00...3000.00 Ω 0.01
Factor K0 zone 3 DSTPDIS 0.0...4.0 0.1
Factor K0 angle Zn3 DSTPDIS -135...135° 1
Gnd operate Dl Zn3 DSTPDIS 20...60000 ms 1
Directional mode Zn4 DSTPDIS 1 = Non-directional
2 = Forward
3 = Reverse
-
R1 zone 4 DSTPDIS 0.00...3000.00 Ω 0.01
X1 zone 4 DSTPDIS 0.00...3000.00 Ω 0.01
X1 reverse zone 4 DSTPDIS 0.00...3000.00 Ω 0.01
Z1 zone 4 DSTPDIS 0.01...3000.00 Ω 0.01
Z1 angle zone 4 DSTPDIS 15.0...90.0° 0.1
Z1 reverse zone 4 DSTPDIS 0.00...3000.00 Ω 0.01
PP operate delay Zn4 DSTPDIS 20...60000 ms 1
R0 zone 4 DSTPDIS 0.00...3000.00 Ω 0.01
X0 zone 4 DSTPDIS 0.00...3000.00 Ω 0.01
Factor K0 zone 4 DSTPDIS 0.0...4.0 0.1
Factor K0 angle Zn4 DSTPDIS -135...135° 1
Gnd operate Dl Zn4 DSTPDIS 20...60000 ms 1
Directional mode Zn5 DSTPDIS 1 = Non-directional
2 = Forward
3 = Reverse
-
R1 zone 5 DSTPDIS 0.00...3000.00 Ω 0.01
X1 zone 5 DSTPDIS 0.00...3000.00 Ω 0.01
X1 reverse zone 5 DSTPDIS 0.00...3000.00 Ω 0.01
Z1 zone 5 DSTPDIS 0.01...3000.00 Ω 0.01
Z1 angle zone 5 DSTPDIS 15.0...90.0° 0.1
Z1 reverse zone 5 DSTPDIS 0.00...3000.00 Ω 0.01
PP operate delay Zn5 DSTPDIS 20...60000 ms 1
