ABB SM500F Door Assembly Replacement

SM500F Color and Monochrome V ideographic Recorders
Door Assembly Replacement 3 Door Assembly Replacement
4 INF08/001 Rev. C
6. Referring to Fig. 3.5, disconnect the keypad membrane cable F from the processor board.
7. Referring to Fig. 3.6, remove the 4 Torx screws G securing the display mounting plate and remove
the plate, complete with the display, ensuring that the keypad membrane cable clears slot H in the
display mounting plate.
Fig. 3.5 Disconnecting the Keypad Membrane Cable
Fig. 3.6 Removing the Display Mounting Plate and Display
F
