-name "smtsigwire1" -detect_input "diSE_DET1" \
-reference_set_output "doSE_REF1" \ -wire_select_output
"doWIRE_SEL1" \ -sensor_on_output "doSE_SENSOR1"
PROC:CFG_1.0:5.0::
# Smartac procSmarTacSpd.cfg file
# created 2005/09/22
SMARTAC_SPEEDS:
# Structure created by SmarTac, defaults filled by SmarTac.
# Cell Layer may overwrite with replace.
-name "smtspeedstd" -main_search_speed 20
groove_search_speed 15
Change settings
To change settings, the user must use the Add or Replace feature to override the
existing fields with new settings. For example, a user could activate the wire search
capability by using the pre-defined predefined wire search I/O set-up:
PROC:CFG_1.0:5.0:
# Example override Smartac proc.cfg file
# created 2005/09/22
#
SMARTAC_SETTINGS:
-name "T_ROB1" -uses_signals "smtsigwire1" -uses_speeds
"smtspeedstd"
Change default I/O names
To change the default I/O names, the user should supply a new I/O settings by
creating new assignments:
PROC:CFG_1.0:5.0:
# Example override Smartac proc.cfg file
# for new signal names.
# created 2005/09/24
#
SMARTAC_SETTINGS:
# Structure created by SmarTac, defaults filled by
# SmarTac. Cell Layer may overwrite with replace.
-name "T_ROB1" -uses_signals "mysmtsig" -uses_speeds "smtspeedstd"
#
SMARTAC_SIGNALS:
-name "mysmtsig" -detect_input "diMyDetect" \
-reference_set_output "doMyRef" \ -wire_select_output
"doMyWireSel" \ -sensor_on_output "doMySensorOn"
