Use SmarTac with ESAB AristoMig touch sense
Below is an example of a configuration that could be used to set up a SmarTac
system with ESAB touch sense. In this case only the software package for SmarTac
is used, no SmarTac hardware should be used, instead the touch sensing capability
of the AristoMig welder is used.
Note
Wire sensing is the default method for ESAB AristoMig. Contact your ESAB
retailer on how to use the gas nozzle as sensor.
EIO:CFG_1.0:5:0::
#
EIO_SIGNAL:
-Name "doTouchSenseActive" -SignalType "DO" -Unit "B_AW_PROC_40"
-UnitMap "15"
-Name "diTouchSenseContact" -SignalType "DI" -Unit "B_AW_PROC_40"
-UnitMap "50"
PROC:CFG_1.0:5.0:
# Example using ESAB AristoMig touch sense for wire or gas sensing
nozzle
#
SMARTAC_SIGNALS:
-name "smtsig1" -detect_input "diTouchSenseContact"\
-reference_set_output ""\ -wire_select_output ""\
-sensor_on_output "doTouchSenseActive"
