30
Parameter Channel Code Default value
Event delay; —>activated 4…13 S10 0.0 s
Event delay; —>reset 4…13 S11 0.0 s
Event reporting 1…13 S20 0 = event reporting enabled
Load default values after EEPROM
failure 0 V152 1 = inhibited
Event mask 0 V155 3
Event mask 1…3 V155 1875
Event mask 4…13 V155 3
Data communication address 0 V200 99
Data transfer rate 0 V201 9600
Technical data Control functions
- status indication for maximum 3 objects, e.g. circuit breakers, disconnectors, earth switches
- configuration freely programmable by the user
- remote or local control (open and close) for one object
- output pulse length programmable, 0.1…100.0 s
- 10 other binary inputs to read contact data other than status information
- feeder oriented interlocking freely programmable, the 3 status inputs and 10 other binary
inputs may be included
- the 10 binary inputs may be used to operate the OPEN and CLOSE outputs
- three signal outputs, can be controlled by the 10 binary inputs
Measurements
- measurement of three phase currents
- phase current measuring range 0…2.5 x I
n
- phase current measuring accuracy better than ±1 % of I
n
- two mA inputs for measuring active and reactive power
- mA input range -20…20 mA, can be limited by programming
- power measuring accuracy better than ±1 % of maximum value of measuring range
- one pulse counter input for energy pulse counting, maximum frequency 25 Hz
- energy can also be calculated on the basis of measured power
- all measured values can be scaled to actual primary values
- local display or remote reading of measured values
