11
Switchgroup SGF6 Selection of the output signal controlling the
TRIP indicator on the front panel. When the
switch linked to a certain signal is in position 1,
the TRIP indicator is lit once the signal is acti-
vated. At the same time the concerned signal
starts the recovery function, provided the recov-
ery output is in use (selected with SGR9/_ ).
Switch Function Factory
setting
SGF6/1 The SS1 signal activates the TRIP indicator and starts the recovery 0
function.
SGF6/2 The TS1 signal activates the TRIP indicator and starts the recovery 1
function.
SGF6/3 The SS2 signal activates the TRIP indicator and starts the recovery 0
function.
SGF6/4 The TS2 signal activates the TRIP indicator and starts the recovery 1
function.
SGF6/5 The SS3 signal activates the TRIP indicator and starts the recovery 0
function.
SGF6/6 The TS3 signal activates the TRIP indicator and starts the recovery 0
function.
SGF6/7 The SS4 signal activates the TRIP indicator and starts the recovery 0
function.
SGF6/8 The TS4 signal activates the TRIP indicator and starts the recovery 0
function.
∑ SGF6 10
Switchgroup SGF7 The switchgroup SGF7 is used for selecting the
rated voltage of the relay module.
Switch Rated voltage Factory
100 V 110 V 115 V 120 V setting
SGF7/1 0 1 0 1 0
SGF7/2 0 0 1 1 0
SGF7/3 When the switch is in position 1, 0
the selected rated voltage is divided by √3.
Then the following voltages are received:
57.7 V 63.5 V 66.4 V 69.3 V
SGF7/4...8 Not in use 0
∑ SGF7 0
