ABB SPAF 140 C - Page 37

23
Setting Actual Main sett. Sec. sett. Setting range
values (R) values values
(R,W,P) (R,W,P)
Operate time t
1
, stage 1 S10 S70 S130 0.10...300.00 s **)
Operate time t
'1
, stage 1 S11 S71 S131 0.10...300.00 s *)
Operate time t
2
, stage 2 S12 S72 S132 0.10...300.00 s **)
Operate time t
'2
, stage 2 S13 S73 S133 0.10...300.00 s *)
Operate time t
3
, stage 3 S14 S74 S134 0.10...300.00 s **)
Operate time t
'3
, stage 3 S15 S75 S135 0.10...300.00 s *)
Operate time t
4
, stage 4 S16 S76 S136 0.10...300.00 s **)
Operate time t
'4
, stage 4 S17 S77 S137 0.10...300.00 s *)
Start value Idf/dtI, stage 1 S18 S78 S138 0.2...10.00 Hz/s
Start value Idf/dtI, stage 2 S19 S79 S139 0.2...10.00 Hz/s
Start value Idf/dtI, stage 3 S20 S80 S140 0.2...10.00 Hz/s
Start value Idf/dtI, stage 4 S21 S81 S141 0.2...10.00 Hz/s
Start value f
r
of recovery function S22 S82 S142 0.1...10.0 Hz
Operate time t
r
of recovery function S23 S83 S143 1 s...120 min 59 s
Checksum, SGF1 S24 S84 S144 0...255
Checksum, SGF2 S25 S85 S145 0...255
Checksum, SGF3 S26 S86 S146 0...255
Checksum, SGF4 S27 S87 S147 0...255
Checksum, SGF5 S28 S88 S148 0...255
Checksum, SGF6 S29 S89 S149 0...255
Checksum, SGF7 S30 S90 S150 0...255
Checksum, SGB1 S31 S91 S151 0...255
Checksum, SGB2 S32 S92 S152 0...255
Checksum, SGB3 S33 S93 S153 0...255
Checksum, SGB4 S34 S94 S154 0...255
Checksum, SGB5 S35 S95 S155 0...255
Checksum, SGB6 S36 S96 S156 0...255
Checksum, SGR1 S37 S97 S157 0...255
Checksum, SGR2 S38 S98 S158 0...255
Checksum, SGR3 S39 S99 S159 0...255
Checksum, SGR4 S40 S100 S160 0...255
Checksum, SGR5 S41 S101 S161 0...255
Checksum, SGR6 S42 S102 S162 0...255
Checksum, SGR7 S43 S103 S163 0...255
Checksum, SGR8 S44 S104 S164 0...255
Checksum, SGR9 S45 S105 S165 0...255
Length of control pulse SS1 S46 S106 S166 0.1...20.0 s
Length of control pulse TS1 S47 S107 S167 0.1...20.0 s
Length of control pulse SS2 S48 S108 S168 0.1...20.0 s
Length of control pulse TS2 S49 S109 S169 0.1...20.0 s
Length of control pulse SS3 S50 S110 S170 0.1...20.0 s
Length of control pulse TS3 S51 S111 S171 0.1...20.0 s
Length of control pulse SS4 S52 S112 S172 0.1...20.0 s
Length of control pulse TS4 S53 S113 S173 0.1...20.0 s
*) The minimum operate time depends on the rated frequency and the number of cycles used for
the measurement. See "Frequency measurement" in the section "Description of operation".
**) If the df/dt function is in use the setting range is 0.15...300.00 s
The setting of operation time is available from program version SW 131 F and later.
