24
Measured value Code Data direction Value
Number of starts, stage 1 V1 R 0...255
Number of starts, stage 2 V2 R 0...255
Number of starts, stage 3 V3 R 0...255
Number of starts, stage 4 V4 R 0...255
Number of trips, stage 1 V5 R 0...255
Number of trips, stage 2 V6 R 0...255
Number of trips, stage 3 V7 R 0...255
Number of trips, stage 4 V8 R 0...255
Number of recovery operations V9 R 0...255
Red operation code of display V10 R 0...10
Minimum df/dt measured V60 R 0.0...-10.0 Hz/s
Minimum frequency measured V61 R 20.00...75.00 Hz
Maximum df/dt measured V62 R 0.0...10.0 Hz/s
Maximum frequency measured V63 R 20.00...75.00 Hz
The parameters V11...V54 can be used to read
(R) the five latest values recorded. Event n is
the most recent value recorded, event n-1 the
previous value, and so on.
Recorded data Event Measuring range
n n-1 n-2 n-3 n-4
Voltage U V11 V21 V31 V41 V51 0.0...1.4 x U
n
Frequency f V12 V22 V32 V42 V52 20.00...75.00 Hz
Frequency rate of change lIdf/dtIl V13 V23 V33 V43 V53 0.0...±10.0 Hz/s
No. of tripped stage and output V14 V24 V34 V44 V54 0, 11, 12, 21,22,
31, 32, 41, 42 *)
*) 11 to be understood as stage 1 timer t
1
, 32 as stage 3 timer t
3'
, etc.
Measured and
recorded parameter
values
