Module Pin Connections
Table 6-3. P 1 P owe r Con nect ion s
Pin Signal Pin Signal
1+5 VDC 7Not used
2+5 VDC 8Not used
3Not used 9Power fail interrupt
4Not used 10Not used
5Common 11Not Used
6Common 12Not Used
Table 6-4. P 2 E xpand er Bus Con nections
Pin Signal Pin Signal
1Data 1 7Data 7
2Data 0 8Data 6
3Data 3 9Clock
4Data 2 10Sync
5Data 5 11Not Used
6Data 4 12Not Used
