ABB Symphony Harmony Series - P3 Input Signal Connections

Module Pin Connections
WBPEEUI240774A0 6 - 9
Table 6-5. P 3 Input Sig nal C on nections
Pin Signal Pin Signal
1RTD- 26RTD+
2IN1+ 27IN1-
3COM1 28COM2
4IN2- 29IN2+
5IN3+ 30IN3-
6COM3 31COM4
7IN4- 32IN4+
8IN5+ 33IN5-
9COM5 34COM6
10 IN6- 35 IN6+
11 IN7+ 36 IN7-
12 COM7 37 COM8
13 IN8- 38 IN8+
14 IN9+ 39 IN9-
15 COM9 40 COM10
16 IN10- 41 IN10+
17 IN11+ 42 IN11-
18 COM11 43 COM12
19 IN12- 44 IN12+
20 IN13+ 45 IN13-
21 COM13 46 COM14
22 IN14- 47 IN14+
23 IN15+ 48 IN15-
24 COM15 49 COM16
25 IN16- 50 IN16+
