Reference Documents

Table 1-2 lists ABB Automation instructions for equipment

that is referenced in this instruction.

Related Nomenclature

Table 1-3 lists nomenclature related to the IMASI23 module.

Specifications

Table 1-4 contains the specifications for the IMASI23 module.

Table 1-2. R efe rence Do cuments

Number Document

WBPEEUI200502?0 Module Mounting Unit (IEMMU11, IEMMU12,

IEMMU21, IEMMU22)

WBPEEUI210504?0 Composer™ Function Code Application Manual

WBPEEUI260046?0 Analog Input Termination Unit (NTAI06)

Table 1-3. R elat ed Nom encla ture

Nomenclature Description

IEMMU11, EMMU12, IEMMU21, IEMMU22 Module mounting unit

NFTP01 Field termination panel

Table 1-4. S pec ification s

Property Characteristic/Value

Power requirements

Operating voltage 5 VDC at 500 mA typical, maximum 750 mA

Overvoltage category

(IEC 61010-1)

I for circuit above 150V,

II for circuit below 150V
