Instruction Content
Instruction Content
This instruction consists of following sections:
Introduction
Overview of the IMASI23 module including features, descrip-
tion, and specifications.
Description and
Operation
Explains the module operation and input circuits.
Installation
Contains the cautions to observe when handling IMASI23 mod-
ules. It shows the steps to install and connect the module
before applying power. This section also covers switch and
jumper settings.
Configuration and
Calibration
Presents steps to configure the analog input module inputs for
specific input types and how to field calibrate an input channel
for a specific input type.
Operating Procedures
Explains the operator interface to the IMASI23 module.
Troubleshooting
Describes the IMASI23 module error codes and explains how to
test the module.
Maintenance
Provides a preventive maintenance schedule for the IMASI23
module. This schedule can be used for all the modules in the
module mounting unit.
Repair and
Replacement
Contains the cautions and steps for removing and replacing
the IMASI23 module.
Appendices
Appendix A provides configuration information for the NTAI06
termination unit. Appendix B provides information on replac-
ing an IMASI13, and Appendix C provides information when
replacing an IMASI03 module.
How to Use this Instruction
Read this instruction in sequence. It is important to become
familiar with the entire contents of this instruction before
using the module. Refer to a specific section for information as
needed.
1. Read the operating procedures section before installing the
module.
2. Perform the steps in the installation section.
