Error Messages and Corrective Actions
Input Channel Status
The ASI module maintains a fixed area in the dual port RAM to
store the current value and status of each channel. The con-
troller reads the data and status for each channel individually.
To view the status of the IMASI23 module, read block output
N+1 of FC 215. Check the input status on each point individu-
ally by looking at the corresponding FC 216 output quality.
2Calibration (02H) problem
report (from FC 215)
Unconfigured
reference error
Cold junction reference is not zero
and has bad quality. Unconfigured
channel reference error (unused
channel not functioning properly).
The I/O module and all configured
channels will continue to function
properly.
Calibration error (02H)
problem report (from FC 215)
Cold junction reference
error
Calibration error (02H)
problem report (from FC 216)
Channel 1-16
reference error
Remove IMASI23 and reinsert. If
error recurs, replace the IMASI23.
1No response/wrong type
(01H) problem report (from
FC 215)
Any communication
failure. Any command
or data failure
No response/wrong type
(01H) problem report (from
FC 215)
NVRAM error
No response/wrong type
(01H) problem report (from
FC 215)
Analog input module
A/D reference error
Calibration error (01H)
problem report (from FC 215)
Analog input module
not calibrated
No response/wrong type
(01H) problem report (from
FC 216)
Channel 1-16 I/O
expander bus error
Remove IMASI23 and reinsert. If
error recurs, replace the IMASI23.
No response/wrong type
(01H) problem report (from
FC 215)
Cold junction I/O
expander bus error
Table 6-1. I MASI23 E rror Type s
(continued)
Module Problem Report Type 12
Error
Type
Error Description
Analog Input Module
Error
Corrective Actions
