ABB TPR56FV Series User Manual

Assembly Instructions / TPR56FV.. - TPR61FV..
1 Introduction / 1.5 Definition of mandatory signs
© Copyright 2018 ABB. All rights reserved. HZTL455311P0033_EN Revision B May 2018
1.5 Definition of mandatory signs
To be worn at all times
Protective clothing Safety footwear to protect
against mechanical hazard and
risk of falling
Table1: Personal protective equipment to be worn at all times
To be worn specific to the respective task
Safety glasses Safety goggles
Safety gloves to protect
against
- Mechanical hazard
- Chemical hazard
- Thermal hazard
- Electrical hazard
Respiratory mask to protect
against
- Dusts
- Gases
Safety helmet Ear protection
Table2: Personal protective equipment to be worn specific to the respective task
1.6 Definition of pictograms
The following pictograms can occur in this document. These point out actions that must be
taken in accordance with the meaning of the relevant pictogram.
Pictogram Meaning Pictogram Meaning
Tighten with specified torque Oil free, grease free and dry
Tighten over specified tightening
angle
Affix
Hand-tight, tighten without tools Measure
Oil Note
Apply screw locking paste (e.g.
Loctite)
Visually inspect
Apply high-temperature grease See document
Apply other paste in accordance
with specifications
Dispose of in an environmentally
compatible, professional way and
in compliance with locally applic-
able regulations.
Table3: Pictograms
Page 4 / 17
