Operation Manual / TPS44-F.. - TPS61-F..
5 Maintenance / 5.4 Cleaning components mechanically
© Copyright 2020 . All rights reserved. HZTL2412_EN Rev.G March 2020
u Pull out the sheet-metal coverings (81137), bend them up and remove
the absorption segments (81136).
u Clean the absorption segments (81136).
During cleaning, ensure that the absorption segments (81136) are
only cleaned with a mild jet of compressed air, soft brush or a damp
cloth.
u Have absorption segments which are heavily contaminated replaced
by an official ABB Turbocharging Service Station.
Fitting the filter silencer
u Insert the absorption segments (81136) into the sheet-metal cover-
ings (81137).
u Bend the sheet-metal coverings (81137) back into their original shape
and insert them into the slot guides in the silencer body (81135).
u Fit the cover grid (81266).
u Fit the tension bands (81270) and apply tension at the locks (81271).
u Damaged tension bands must be replaced with new ones.
u If provided, fit the filter ring (81265).
Page 58 / 113
