7 Removal and installation
7.1 Transport
Suspension of uninsulated turbocharger
Turbocharger with oil-cooled bearing
casing
Complete turbocharger with gas out-
let casing
Suspension of insulated turbocharger
Turbocharger with oil-cooled bearing
casing
Complete turbocharger with gas out-
let casing
