Operation Manual / TPS44-F.. - TPS61-F..
7 Removal and installation / 7.4 Installing the turbocharger
© Copyright 2020 . All rights reserved. HZTL2412_EN Rev.G March 2020
u Fasten all gas, water and air lines in accordance with the engineb-
uilder's instructions.
If present:
u Fit speed sensor and plug in cable connector.
u Adapt and fit bearing casing insulation(A).
u Adapt and fit sheet metal(B) of bearing casing insulation.
Version with water-cooled bearing casing:
u Remove the screw plugs from the water connections and fit the water
pipes in accordance with the enginebuilder's instructions.
Page 77 / 113
